Feature:
- Large Head/Standard head
- NSK style Pana Max high speed handpiece
- 2 hole push button handpiece
- Single water spray
- It has unique appearance design and fluent outline.
- Smooth as silk, it has excellent texture.
- With people-friendly design, easy for operation.
- With best quality cartridge, easier for cleaning.
- With high-speed turbine rotation, it has better performances.
- It is noise-free and stable.
- Applicable Bur: 1.6mm and should be conformed to ISO standard.
- Idling speed of handpiece should be no less than 370,000 rotations under working air pressure of 25-30 pressure atmosphere.
- Special for operations such as clamping high-speed dentistry machine needle to drill and grind teeth in department of stomatology, it is more professional.
- It is only for people who have dentistry medical qualification.
Specification:
|
Description |
Big Head Push button type, high speed handpiece, single water spray 2 hole |
|
Needle change Type |
Push button |
|
Air Pressure at the back end of HP |
206~231 KPa (2.1~2.35 kgf/cm2) |
|
Air pressure at the guage in the dental unit |
240-294 KPa (2.45-3.0 kgf/cm2) |
|
Water Pressure |
198Kpa (2 kg) |
|
Rotation Speed |
370,000-420,000 rpm |
|
Head Hight |
13.14 mm |
|
Head Diameter |
φ12.5 mm |
|
Bur Applicable |
φ1.59mm~φ1.6mm×21mm~23mm (diameter×length) |
|
Noise |
≤70dB |
